Hallo,
ich habe hier ein Ruby Script welches soweit auch tadellos funktioniert. Dieses Script fragt Korpusmaße ab und die Anzahl der Fronten die übereinander bzw. nebeneinander angeordnet werden sollen und wie breit die Fugen dazwischen sein sollen, bzw. ob die Fronten links oder rechts überstehen sollen.
Dabei ist die Front, wenn nicht "Sonderanfertigung" allseitig 2 mm kleiner als der Korpus, bzw. wenn die Fuge oberhalb der Front 30 mm beträgt, bekommt der Korpus eine Ausklinkung. Alles soweit gut und es funktioniert.
Ich weiß, dass der Korpus 810 mm hoch wird, wenn ich den Wert in der Abfrage nicht ändere. Wenn ich in der Korpusabfrage nun sage, dass ich zwei Fronten übereinander haben möchte, dann werden nacheinander die Fronten und Fugen abgefragt.
Ergo müsste es möglich sein bei der zweiten Front zu sagen, dass er die Korpushöhe minus der Frontfuge oben (der ersten Front) minus der Höhe der ersten Front und minus der Frontfuge unten (der ersten Front) errechnen soll und anstelle des im Script fettmarkierten Fronthöhenwertes bei der Abfrage der zweiten Front zumindest vorschlägt.
Wenn ich nun bei dem Vorschlagswert der zweiten Front anstelle der rot markierten 158 mm dort reinschreiben würde “zz(korpushöhe)-fso1(Frontspalt oben erste Front)-fh1(Frontteilhöhe erste Front)-fsu1(Frontspalte unten erste Front)“ bekomme ich einen Fließkommazahl in der Abfrage angezeigt. Wenn ich die bestätige bekomme ich zwar das gewünschte Ergebnis aber wenn ich den Wert wieder mit 158 überschreibe, dann wird die zweite Front halt nicht mehr 158 mm hoch sondern um ein x-faches höher (undefiniert und unberechenbar).
Lange Rede kurzer Sinn, wie bekomme ich es hin, dass er mit ganzen Zahlen rechnet und keine Fließkommazahlen auswirft, die nicht zuzuordnen sind?
jemand eine Idee?
Hier das Script...
Code: #-------------------------------------------------------------------------------
require 'sketchup.rb'
require 'new2/nmat1.rb'
def new2_xu
prompts = [hs, os, us, breite, hoehe, tiefe, fanzahlv, fanzahlh, rwstaerke]
values = [0, 0, 1, 600.mm, 810.mm, 625.mm, 1, 1, 8.mm]
results = inputbox prompts, values, nav120
return if not results
hs, os, us, xx, zz, yy, fav, fah, r1 = results
d1 = 19.mm
z1 = 19.mm
fah = 2 if fah>2
if yy<=525.mm
rws = 25.mm
else rws = 48.mm
end
if fav>=1
prompts = [spaltoben1, fhoehe1, spaltunten1, fbreite1, fstaerke1, fabstand1, fueberstandl1, fueberstandr1, fueberstandu1]
values = [30.mm, 158.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav111
return if not results
fso1, fh1, fsu1, fbr1, fst1, fab1, ful1, fur1, fuu1 = results
model = Sketchup.active_model
model.start_operation "1.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful1, 0.mm-fst1-fab1, zz-fso1-fh1]
pts[1] = [0.mm-ful1, 0.mm-fab1, zz-fso1-fh1]
pts[2] = [0.mm-ful1, 0.mm-fab1, zz-fso1]
pts[3] = [0.mm-ful1, 0.mm-fst1-fab1, zz-fso1]
base = entities.add_face pts
base.pushpull fbr1+ful1+fur1
model.commit_operation
group.name = "Front1"
if fso1>29.mm
tra = 49.mm
end
if fso1<29.mm
tra = 0.mm
end
end
if fav>=2
prompts = [spaltoben2, fhoehe2, spaltunten2, fbreite2, fstaerke2, fabstand2, fueberstandl2, fueberstandr2, fueberstandu2]
values = [fsu1, [color=#C14700][b]158.mm[/b][/color], 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav112
return if not results
fso2, fh2, fsu2, fbr2, fst2, fab2, ful2, fur2, fuu2 = results
model = Sketchup.active_model
model.start_operation "2.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful2, 0.mm-fst2-fab2, zz-fso1-fh1-fso2-fh2]
pts[1] = [0.mm-ful2, 0.mm-fab2, zz-fso1-fh1-fso2-fh2]
pts[2] = [0.mm-ful2, 0.mm-fab2, zz-fso1-fh1-fso2]
pts[3] = [0.mm-ful2, 0.mm-fst2-fab2, zz-fso1-fh1-fso2]
base = entities.add_face pts
base.pushpull fbr2+ful2+fur2, true
model.commit_operation
group.name = "Front2"
else
fso2=0
end
if fav>=3
prompts = [fhoehe3, spaltoben3, fbreite3, fstaerke3, fabstand3, fueberstandl3, fueberstandr3, fueberstandu3]
values = [158.mm, fsu2, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav113
return if not results
fh3, fso3, fbr3, fst3, fab3, ful3, fur3, fuu3 = results
model = Sketchup.active_model
model.start_operation "3.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful3, 0.mm-fst3-fab3, zz-fso1-fh1-fso2-fh2-fso3-fh3]
pts[1] = [0.mm-ful3, 0.mm-fab3, zz-fso1-fh1-fso2-fh2-fso3-fh3]
pts[2] = [0.mm-ful3, 0.mm-fab3, zz-fso1-fh1-fso2-fh2-fso3]
pts[3] = [0.mm-ful3, 0.mm-fst3-fab3, zz-fso1-fh1-fso2-fh2-fso3]
base = entities.add_face pts
base.pushpull fbr3+ful3+fur3
model.commit_operation
group.name = "Front3"
else
fso3=0
end
if fav>=4
prompts = [fhoehe4, spaltoben4, fbreite4, fstaerke4, fabstand4, fueberstandl4, fueberstandr4, fueberstandu4]
values = [778.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav114
return if not results
fh4, fso4, fbr4, fst4, fab4, ful4, fur4, fuu4 = results
model = Sketchup.active_model
model.start_operation "4.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful4, 0.mm-fst4-fab4, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4]
pts[1] = [0.mm-ful4, 0.mm-fab4, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4]
pts[2] = [0.mm-ful4, 0.mm-fab4, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4]
pts[3] = [0.mm-ful4, 0.mm-fst4-fab4, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4]
base = entities.add_face pts
base.pushpull fbr4+ful4+fur4
model.commit_operation
group.name = "Front4"
else
fso4=0
end
if fav>=5
prompts = [fhoehe5, spaltoben5, fbreite5, fstaerke5, fabstand5, fueberstandl5, fueberstandr5, fueberstandu5]
values = [778.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav115
return if not results
fh5, fso5, fbr5, fst5, fab5, ful5, fur5, fuu5 = results
model = Sketchup.active_model
model.start_operation "5.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful5, 0.mm-fst5-fab5, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5]
pts[1] = [0.mm-ful5, 0.mm-fab5, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5]
pts[2] = [0.mm-ful5, 0.mm-fab5, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5]
pts[3] = [0.mm-ful5, 0.mm-fst5-fab5, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5]
base = entities.add_face pts
base.pushpull fbr5+ful5+fur5
model.commit_operation
group.name = "Front5"
else
fso5=0
end
if fav>=6
prompts = [fhoehe6, spaltoben6, fbreite6, fstaerke6, fabstand6, fueberstandl6, fueberstandr6, fueberstandu6]
values = [778.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav116
return if not results
fh6, fso6, fbr6, fst6, fab6, ful6, fur6, fuu6 = results
model = Sketchup.active_model
model.start_operation "6.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful6, 0.mm-fst6-fab6, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6]
pts[1] = [0.mm-ful6, 0.mm-fab6, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6]
pts[2] = [0.mm-ful6, 0.mm-fab6, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6]
pts[3] = [0.mm-ful6, 0.mm-fst6-fab6, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6]
base = entities.add_face pts
base.pushpull fbr6+ful6+fur6
model.commit_operation
group.name = "Front6"
else
fso6=0
end
if fav>=7
prompts = [fhoehe7, spaltoben7, fbreite7, fstaerke7, fabstand7, fueberstandl7, fueberstandr7, fueberstandu7]
values = [778.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav117
return if not results
fh7, fso7, fbr7, fst7, fab7, ful7, fur7, fuu7 = results
model = Sketchup.active_model
model.start_operation "7.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful7, 0.mm-fst7-fab7, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7]
pts[1] = [0.mm-ful7, 0.mm-fab7, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7]
pts[2] = [0.mm-ful7, 0.mm-fab7, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7]
pts[3] = [0.mm-ful7, 0.mm-fst7-fab7, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7]
base = entities.add_face pts
base.pushpull fbr7+ful7+fur7
model.commit_operation
group.name = "Front7"
else
fso7=0
end
if fav>=8
prompts = [fhoehe8, spaltoben8, fbreite8, fstaerke8, fabstand8, fueberstandl8, fueberstandr8, fueberstandu8]
values = [778.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav118
return if not results
fh8, fso8, fbr8, fst8, fab8, ful8, fur8, fuu8 = results
model = Sketchup.active_model
model.start_operation "8.Front"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [0.mm-ful8, 0.mm-fst8-fab8, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-fso8-fh8]
pts[1] = [0.mm-ful8, 0.mm-fab8, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-fso8-fh8]
pts[2] = [0.mm-ful8, 0.mm-fab8, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-fso8]
pts[3] = [0.mm-ful8, 0.mm-fst8-fab8, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-fso8]
base = entities.add_face pts
base.pushpull fbr8+ful8+fur8
model.commit_operation
group.name = "Front8"
else
fso8=0
end
if fah>=2
if fav>=1
prompts = [fhoehe9, spaltoben9, fbreite9, fstaerke9, fabstand9, fueberstandl9, fueberstandr9, fueberstandu9]
values = [778.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav119
return if not results
fh9, fso9, fbr9, fst9, fab9, ful9, fur9, fuu9 = results
model = Sketchup.active_model
model.start_operation "1.Frontrechts"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [fbr1-ful9, -fab9, zz-fso9]
pts[1] = [fbr1+fbr9+fur9, -fab9, zz-fso9]
pts[2] = [fbr1+fbr9+fur9, -fst9-fab9, zz-fso9]
pts[3] = [fbr1-ful9, -fst9-fab9, zz-fso9]
base = entities.add_face pts
base.pushpull fh9
model.commit_operation
group.name = "Frontrechts1"
end
if fav>=2
prompts = [fhoehe10, spaltoben10, fbreite10, fstaerke10, fabstand10, fueberstandl10, fueberstandr10, fueberstandu10]
values = [778.mm, 30.mm, xx, 19.mm, 3.mm, -2.mm, -2.mm, 0.mm]
results = inputbox prompts, values, nav121
return if not results
fh10, fso10, fbr10, fst10, fab10, ful10, fur10, fuu10 = results
model = Sketchup.active_model
model.start_operation "2.Frontrechts"
entities = model.active_entities
group = entities.add_group
entities = group.entities
pts = []
pts[0] = [fbr2-ful10, 0.mm-fst10-fab10, zz-fso9-fh9-fso10-fh10]
pts[1] = [fbr2-ful10, 0.mm-fab10, zz-fso1-fh9-fso10-fh10]
pts[2] = [fbr2-ful10, 0.mm-fab10, zz-fso1-fh9-fso10]
pts[3] = [fbr2-ful10, 0.mm-fst10-fab10, zz-fso9-fh9-fso10]
base = entities.add_face pts
base.pushpull fbr10+ful10+fur10, true
model.commit_operation
group.name = "Frontrechts2"
end
end
##
model = Sketchup.active_model
model.start_operation "korpus"
entities = model.active_entities
group = entities.add_group
entities = group.entities
#seite links
pts = []
pts[0] = [0.mm, 0.mm, 0.mm]
pts[1] = [0.mm, 0.mm, zz]
pts[2] = [0.mm, yy, zz]
pts[3] = [0.mm, yy, 0.mm]
face = entities.add_face pts
status = face.pushpull -d1, true
if fso1>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-64.mm]
pts[1] = [0.mm, 0.mm, zz]
pts[2] = [0.mm, +49.mm, zz]
pts[3] = [0.mm, +49.mm, zz-64.mm]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso2>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-fso1-fh1+fuu1]
pts[1] = [0.mm, 0.mm, zz-fso1-fh1-64.mm]
pts[2] = [0.mm, +49.mm, zz-fso1-fh1-64.mm]
pts[3] = [0.mm, +49.mm, zz-fso1-fh1+fuu1]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso3>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2+fuu2]
pts[1] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-64.mm]
pts[2] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-64.mm]
pts[3] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2+fuu2]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso4>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3+fuu3]
pts[1] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-64.mm]
pts[2] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-64.mm]
pts[3] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3+fuu3]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso5>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4+fuu4]
pts[1] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-64.mm]
pts[2] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-64.mm]
pts[3] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4+fuu4]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso6>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5+fuu5]
pts[1] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-64.mm]
pts[2] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-64.mm]
pts[3] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5+fuu5]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso7>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6+fuu6]
pts[1] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-64.mm]
pts[2] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-64.mm]
pts[3] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6+fuu6]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso8>29.mm
pts = []
pts[0] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7+fuu7]
pts[1] = [0.mm, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-64.mm]
pts[2] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-64.mm]
pts[3] = [0.mm, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7+fuu7]
face = entities.add_face pts
status = face.pushpull +d1, false
end
#seite rechts
pts = []
pts[0] = [xx-d1, 0.mm, 0.mm]
pts[1] = [xx-d1, 0.mm, zz]
pts[2] = [xx-d1, yy, zz]
pts[3] = [xx-d1, yy, 0.mm]
face = entities.add_face pts
status = face.pushpull -d1, true
if fso1>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-64.mm]
pts[1] = [xx-d1, 0.mm, zz]
pts[2] = [xx-d1, +49.mm, zz]
pts[3] = [xx-d1, +49.mm, zz-64.mm]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso2>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-fso1-fh1+fuu1]
pts[1] = [xx-d1, 0.mm, zz-fso1-fh1-64.mm]
pts[2] = [xx-d1, +49.mm, zz-fso1-fh1-64.mm]
pts[3] = [xx-d1, +49.mm, zz-fso1-fh1+fuu1]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso3>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2+fuu2]
pts[1] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-64.mm]
pts[2] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-64.mm]
pts[3] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2+fuu2]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso4>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3+fuu3]
pts[1] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-64.mm]
pts[2] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-64.mm]
pts[3] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3+fuu3]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso5>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4+fuu4]
pts[1] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-64.mm]
pts[2] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-64.mm]
pts[3] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4+fuu4]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso6>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5+fuu5]
pts[1] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-64.mm]
pts[2] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-64.mm]
pts[3] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5+fuu5]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso7>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6+fuu6]
pts[1] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-64.mm]
pts[2] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-64.mm]
pts[3] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6+fuu6]
face = entities.add_face pts
status = face.pushpull +d1, false
end
if fso8>29.mm
pts = []
pts[0] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7+fuu7]
pts[1] = [xx-d1, 0.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-64.mm]
pts[2] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7-64.mm]
pts[3] = [xx-d1, +49.mm, zz-fso1-fh1-fso2-fh2-fso3-fh3-fso4-fh4-fso5-fh5-fso6-fh6-fso7-fh7+fuu7]
face = entities.add_face pts
status = face.pushpull +d1, false
end
#boden
if us > 0
pts = []
pts[0] = [0.mm+d1, 0.mm, 0.mm]
pts[1] = [xx-d1, 0.mm, 0.mm]
pts[2] = [xx-d1, yy-rws, 0.mm]
pts[3] = [0.mm+d1, yy-rws, 0.mm]
face = entities.add_face pts
status = face.pushpull -z1, true
end
if os > 0
pts = []
pts[0] = [0.mm+d1, 0.mm, 0.mm]
pts[1] = [xx-d1, 0.mm, 0.mm]
pts[2] = [xx-d1, yy, 0.mm]
pts[3] = [0.mm+d1, yy, 0.mm]
face = entities.add_face pts
status = face.pushpull -z1, true
end
if hs > 0
pts = []
pts[0] = [0.mm+d1, 0.mm, 0.mm]
pts[1] = [xx-d1, 0.mm, 0.mm]
pts[2] = [xx-d1, yy-rws, 0.mm]
pts[3] = [0.mm+d1, yy-rws, 0.mm]
face = entities.add_face pts
status = face.pushpull -z1, true
end
#traverse1
if us > 0
#
# pts = []
# pts[0] = [0.mm+d1, 0.mm+yy-48.mm-56.mm, 0.mm+zz]
# pts[1] = [0.mm+xx-d1, 0.mm+yy-48.mm-56.mm, 0.mm+zz]
# pts[2] = [0.mm+xx-d1, yy-48.mm, 0.mm+zz]
# pts[3] = [0.mm+d1, yy-48.mm, 0.mm+zz]
#
# face = entities.add_face pts
# status = face.pushpull -z1, true
#traverse2
# pts = []
# pts[0] = [0.mm+d1, tra, 0.mm+zz]
# pts[1] = [0.mm+xx-d1, tra, 0.mm+zz]
# pts[2] = [0.mm+xx-d1, yy-48.mm, 0.mm+zz]
# pts[3] = [0.mm+d1, yy-48.mm, 0.mm+zz]
#
# face = entities.add_face pts
# status = face.pushpull -z1, true
end
#boden2
if us > 0
pts = []
pts[0] = [0.mm+d1, tra, 0.mm+zz]
pts[1] = [0.mm+xx-d1, tra, 0.mm+zz]
pts[2] = [0.mm+xx-d1, yy-rws, 0.mm+zz]
pts[3] = [0.mm+d1, yy-rws, 0.mm+zz]
face = entities.add_face pts
status = face.pushpull -z1, true
end
if hs > 0
pts = []
pts[0] = [0.mm+d1, tra, 0.mm+zz]
pts[1] = [0.mm+xx-d1, tra, 0.mm+zz]
pts[2] = [0.mm+xx-d1, yy-rws, 0.mm+zz]
pts[3] = [0.mm+d1, yy-rws, 0.mm+zz]
face = entities.add_face pts
status = face.pushpull -z1, true
end
if os > 0
pts = []
pts[0] = [0.mm+d1, 0.mm, 0.mm+zz]
pts[1] = [0.mm+xx-d1, 0.mm, 0.mm+zz]
pts[2] = [0.mm+xx-d1, yy, 0.mm+zz]
pts[3] = [0.mm+d1, yy, 0.mm+zz]
face = entities.add_face pts
status = face.pushpull -z1, true
end
#ruecken
if us > 0
pts = []
pts[0] = [d1, 0.mm+yy-rws, zz]
pts[1] = [xx-d1, 0.mm+yy-rws, zz]
pts[2] = [xx-d1, 0.mm+yy+r1-rws, zz]
pts[3] = [d1, 0.mm+yy+r1-rws, zz]
base = entities.add_face pts
base.pushpull +zz, true
end
if os > 0
pts = []
pts[0] = [d1, 0.mm+yy-rws, zz-19.mm]
pts[1] = [xx-d1, 0.mm+yy-rws, zz-19.mm]
pts[2] = [xx-d1, 0.mm+yy+r1-rws, zz-19.mm]
pts[3] = [d1, 0.mm+yy+r1-rws, zz-19.mm]
base = entities.add_face pts
base.pushpull +zz-38.mm, true
end
if hs > 0
pts = []
pts[0] = [d1, 0.mm+yy-rws, zz]
pts[1] = [xx-d1, 0.mm+yy-rws, zz]
pts[2] = [xx-d1, 0.mm+yy+r1-rws, zz]
pts[3] = [d1, 0.mm+yy+r1-rws, zz]
base = entities.add_face pts
base.pushpull +zz, true
end
model.commit_operation
group.name = "korpus"
##
end
if( not file_loaded?("new2_xu.rb") )
end
#-----------------------------------------------------------------------------
file_loaded("new2_xu.rb")
|
!
.
